MDT-1A / MDT-2A Linear Remotes

The MDT-1A is a 1-button Linear MegaCode remote. The MDT-2A is the 3-button version. Both are factory coded at 318 MHz and learn into a MegaCode opener or receiver. The same instruction sheet covers both remotes.

Overview

Linear MDT-1A 1-button MegaCode remote — Linear MDT-1A

Linear MDT-2A 3-button MegaCode remote — Linear MDT-2A

MegaCode Learn button

These remotes work with Linear MegaCode openers and receivers. The opener or receiver learns the remote. Click the photo to enlarge.

The MDT-1A is one channel. The front button and the small top button send the same signal. The top button can be covered with the supplied cap. Part number DNT00052A. Two CR2032 batteries. 318 MHz. Visor clip included.

The MDT-2A is three channel. Two buttons on the face and one on the top. Each button can be programmed to a different opener or receiver. Part number DNT00053A. Two CR2032 batteries. 318 MHz. Visor clip included.

Both remotes are factory preprogrammed with one of over 1,000,000 MegaCode codes. After the remote is programmed to the opener, a vehicle with Homelink can usually learn that remote. Check the car owner’s manual for the Homelink steps.

Compatible Linear openers: LDCO863B, LDCO841, LDCO852, LDCO850, LDCO801, LDCO800, LSO50, LDO50, LDO33, LCO75, Nice Linear 621, and Nice Linear 661.

Compatible MegaCode receivers: MGR, MGR-2, SMDRG, MDR, MDR-2, and MDRU.

Compatible MegaCode keypads: NMTK, LPWKP, and MDTK.

Not every compatible opener or receiver is listed here. This same MegaCode list applies to the other Linear MegaCode remotes and keypads.
